SUPPORTED VEHICLE DETAILS

Chrysler

Make

Pacifica

Model

2020

Year
System RFH Type 3
Add-A-Key Yes
All-Keys-Lost Yes
PIN Read Yes
Programs Remotes Yes, programs with key
Programs Remotes Yes, programs with key
Resync Available No
Notes:

Requires use of a bypass cable, such as the ADC2011, TDB084, FCA Ultimate Chrysler Gateway Bypass, or Chrysler Bypass Cable by Xtool, STAR connector is located on the passenger rear side door pillar, behind a small cover. Open the door, look to the left, open cover and it is right there. Will Require internet connection.

Compatible Parts List

MFK-083 Refill Blades 10-PackAcA A Chrysler Y157/Y159
