1732199047 Supported Vehicles 17378

SUPPORTED VEHICLE DETAILS

RAM

Make

ProMaster 1500

Model

2023

Year
System RFH (Fiat PreCode)
Add-A-Key Not Supported
All-Keys-Lost Not Supported
PIN Read
Programs Remotes Not Supported
Programs Remotes Not Supported
Resync Available No
Notes:

All Promasters require the use of KC100 or KC501 to precode keys. Any key not available at time of programming will become useless. Active alarm with no key available will most likely require BCM replacement. 14-16 will require disconnecting the battery for 20 seconds after pin/precoding, or the vehicle will not start. 17-19 does not require battery disconnect. 20+ may not be supported, but requires the use of the 12+8 bypass cable. The gateway is located behind the glove box. There are a number of screws to remove, some on the sides, and above the glove box. You'll find the gateway buried in behind.

Compatible Parts List

Compatible parts list not found.
