| System | RFH Type 5 |
|---|---|
| Add-A-Key | Yes |
| All-Keys-Lost | Yes |
| PIN Read | Yes |
| Programs Remotes | Yes, Programs with key |
| Programs Remotes | Yes, Programs with key |
| Resync Available | No |
Notes:
Requires use of a bypass cable, such as the ADC2011, TDB084, FCA Ultimate Chrysler Gateway Bypass, or Chrysler Bypass Cable by Xtool, STAR connector is located behind the headlight switch, left of steering wheel. Pull off the edge plate between door and dash, and you can snake your hand in to plug in the cable. Will Require internet connection.
